The 400KVA dry type transformer is a medium-capacity distribution transformer frequently specified for indoor power systems. Rated at 400kVA, it delivers roughly 320kW active power at a 0.8 power factor, sufficient to support medium-scale electrical loads.
Having spent years visiting site installations and witnessing project decision-making, I've seen how this model stands out for indoor applications. Unlike oil-immersed alternatives, it uses epoxy resin to encapsulate copper windings, relying on air cooling either by natural convection (AN) or forced air (AF). No insulating oil means zero risk of leakage or fire spread. It runs with low partial discharge and tolerates humid or dusty indoor environments well.
Built with silicon steel core, epoxy cast HV windings and foil or wire LV windings, the standard 10kV/0.4kV variant steps down grid medium voltage to 400V for site equipment. Dyn11 connection group helps limit zero-sequence current and keeps three-phase voltage balanced.
From my field experience, this transformer is almost always the go-to choice for hospital power rooms, metro auxiliary supply, data center backup power and factory workshops. It removes the need for oil pits and heavy fire partition walls, cutting civil construction costs and saving floor space. Maintenance work is relatively light: regular dust removal, terminal tightening and continuous temperature monitoring.
I also want to share a common pitfall I've run into on multiple projects. Many clients fixate on the fire safety benefit but overlook two key downsides. Dry type units come with higher unit cost and audible noise compared to oil transformers. One project I worked on had designers skimp on ventilation duct space; after commissioning, the transformer hit over-temperature alarms under sustained heavy load. That's why adequate airflow and matched temperature control systems are non-negotiable for long-term reliable operation.
